Page 8 - Safety Express Surface Prep 2018
P. 8
GRINDERS & POLISHERS
Diamatic machines have an excellent reputation and history for quality. Engineered and developed
for improved efficiency, high productivity and achieving consistent results, our systems can be
used with many tooling options for various applications in a wide range of marketsfrom surface
preparation to high gloss polishing.
BMG-780-ULTRAPRO RS BMG-780-PRO
• Grinding Width: 30" • Grinding Width: 30"
• Tool Diameter: 9" • Tool Diameter: 9"
• Motor Power: 23HP Electric Motor • Tooling Speed: 400-1200 RPM
• Power: 230/480v, 3o, 60HZ • Head Pressure: 700-750 lb.
• Amperage: 32/63 Amp • Motor: Electric
• Head Pressure: 700-800 lbs. • Amperage: 32/63 A
• Dust Hose Connection: 3" • Voltage: 230/480V, 3ø, 60 Hz
• Dimensions: 83" L x 31" W x 49" H • Dust Hose Connection: 3"
• Weight: 1245 lbs. • Dimensions: 83" L x 31" W x 49" H
• Weight: 961 lbs.
ITEM DESCRIPTION ITEM DESCRIPTION
DIA-BMG-780-230-RS-V2 BMG-780RS ULTRAPRO Remote Control Grinder, 230V DIA-BMG-780-230/3/60-V2 BMG-780 PRO Grinder/Polisher 30", 23HP Electric Motor, 230V
DIA-BMG-780-460-RS-V2 BMG-780RS ULTRAPRO Remote Control Grinder, 460V DIA-BMG-780-460/3/60-V2 BMG-780 PRO Grinder/Polisher 30", 23HP Electric Motor, 460V
BMG-735-PRO BMG-555-PRO
• Grinding Width: 29" • Grinding Width: 22"
• Tool Diameter: 9" • Tool Diameter: 7"
• Motor: 17HP Electric Motor • Tooling Speed: 350-1100 RPM
• Amperage: 32/63 A • Motor Speed: 580-1750 RPM
• Power: 230/480V, 3ø, 60 Hz • Motor: 7.37hp Electric Motor
• Dust Hose Connection: 3" • Amperage: 32/63 A
• Dimensions: 81" L x 29" W x 46"H • Voltage: 230V, 1ø, 60 Hz
• Weight: 740 lbs. • Dust Hose Connection: 3"
• Dimensions: 81" L x 22" W x 46"H
• Weight: 600 lbs.
ITEM DESCRIPTION ITEM DESCRIPTION
DIA-BMG-735-230/3/60-V2 BMG-735 PRO Grinder/Polisher 29", 17HP Electric Motor, 230V DIA-BMG-555-155KW-230V-R BMG-555 PRO Grinder/Polisher 22", single phase 230V planetary grinder
DIA-BMG-735-460/3/60-V2 BMG-735 PRO Grinder/Polisher 29", 17HP Electric Motor, 460V
BMG-735-PRO PROPANE DIA-BMG-555P
• Grinding Width: 28" • 656cc Briggs and Stratton Commercial Series Engine
• Tool Diameter: 9" • Most powerful machine in its class
• Tooling Speed: 350-1100 RPM • 3 year unlimited hour engine warranty
• Motor: 993 cc Propane (LP) • True gaseous heads designed to run LP
• Dust Hose Connection: 3" • HD centrifugal clutch made in USA
• Battery Power: 12V • Quick change primary belt system
• Drive System: Triple Head Planetary System • HD vernier throttle gives infnite control of engine rpm
• Dimensions: 60" L x 27" W x 52" H • AGM 12V battery
• Weight: 890 lbs. • LED lights fore and aft
• 6 gallon water tank
ITEM DESCRIPTION ITEM DESCRIPTION
DIA-BMG-735-P BMG-735 PRO Grinder/Polisher 29", Propane Powered DIA-BMG-555P BMG-555P Grinder Polisher, Propane Powered
